Location:Home  >  Product center  >  Graphic lattice LCD module  >  Standard COB LCD Module  >  3.2"128X64單色圖形液晶模塊|帶黃綠背光|STN(+)|5.0v|并行接口|Arduino HTM12864A-01Y-A5P
  • Model : 3.2"128X64 monochrome graphic LCD module|with yellow-green backlight|STN(+) | 5.0v | Arduino HTM12864A-01Y-A5P

    Product type:Graphic LCD Module

    Show contents:128x64

    Outline size(mm) :113.0x65.0x12.7

    Size of View Window(mm):72.0x39.5

    Display size(mm) :66.52x33.24

    Point spacing(mm):0.52x0.52

    Product application:Instruments

    Visual angle:6H

    Backlight type or brightness:YG

    Connection PIN Number:20PIN

    Interface mode:MCU

    Special instructions:Anti-static ESD 8KV

    Working temperature:-20~70℃

    Power supply voltage:5.0V

    Driver chip model:K0108

    PDF download
Product description

HTM12864A-01Y-A5P | 128X64 Monochrome Graphic LCD Module | With Yellow-Green Backlight | STN(+) | 5.0v | Parallel Interface |  Arduino

This 128x64 LCD Graphic Display Module displays black pixels on a bright yellow-green background. This transferable LCD display is designed to provide ideal visibility in a variety of lighting conditions in many different environments. In bright sunlight, the display uses its reflective layer to reflect ambient light back to the viewer, making the screen easy to read. In darker environments, the LCD screen has a powerful built-in backlight to provide high contrast and display bright graphics for the viewer. This advanced display technology ensures that the display is always easy to read regardless of the lighting conditions.

This LCD display graphic module is fully compatible with Arduino and can be perfectly connected to other electronic systems for a wide range of applications. The HTM12864-01Y-A5P is designed to withstand harsh operating conditions and has an operating temperature of -20 degrees Celsius to +70 degrees Celsius
